DIEN36PA Dual Isolated Power 5-32V to +-12V 24V DC DC Boost-Buck Converter

DIEN36PA Dual Isolated Power 5-32V to +-12V 24V DC DC Boost-Buck Converter

  • Model: DIEN36PB_12V
  • Availability: In stock
  • Weight: 0.04Kg
$7.99
  • Description
  • Technical Documents
  • Guidance videos
  • Reviews
  • Shipping & Returns
Product Name:DIEN36PA  Dual Isolated Power 5-32V to +-12V  DC DC Boost-Buck Converter
Applications

ADC/DAC/Operational Amplifier

RS232 RS485 RS422 Bus

Audio equipment

Low power audio power supply

Car audio amplifier dual power board

LCD power supply

Instrumentation equipment

Instrumentation multimeter




Description:

2 in 1 Isolated DC-DC Boost-Buck Converter

Input Voltage Range: 5-32 VDC

Output Voltage : ±12V/+24V(MAX 700MA); ±15V/+30V(MAX 550MA)

Minimum Load Requirements: 0% (as+24V/+30V Output), 10% (as +-12/+-15 Output)

Efficiency : 70%-88%

Quiescent current : 68mA(Input 12V)

Low Noise : 50mV

Hihg Accuracy :+/-1%

Working frequency 400KHz

Isolation (Input to Output): 1500VDC minimum (1 minute)

Isolation Capacitance: 1200pF

Short Circuit Protection

Operating ambient temperature : -40~+85 Degrees Celsius

Storage Temperature Range: -55 to +125 Degrees Celsius

Size : 68 x 44 x 16mm

Weight : 39g(With terminal), 34g(no terminal)


+-12V/+24V


    +-15V/+30V






Pin description:

VIN : Input positive

GND : Input negative

EN : Input enable (NC or VIN enable, GND disabled)

V+ : Isolated output positive voltage

COM : Isolated output common

V- : Isolated output negative voltage






Attention :

This is a DC-DC voltage converter module,Must be noted when using:


1 Input voltage can not be greater than the maximum input range


2 Output power can not be greater than the maximum load for a long time


3 Input power must be greater than the output power, because the power consumption of the module itself
