The popular link is like this: MCU -> Encoder -> Transmitter ------ Receiver -> Decoder -> MCU,
PT2262(Encoder) are optional, their existence is to 1)avoid confusing when multiple RF links in range 2) isolate disturbance.
Model No. | TB195 Encoder Transmitter |
Function discription | Encoder Transmitter modules |
Operating voltage |
3V ~ 12V DC
|
Static current |
max≤8mA(12V), min≤2mA(3V)
|
Operating frequency | 433MHz |
modulation Mode | ASK/OOK |
SAW Frequency stability | ±150kHz(max) |
Transmitter Power | 50mW (315MHz, 12V) |
Data rate | ≤10Kbps |
Antenns length | 24 cm (315 MHz), 18 cm (433.92 MHz) |
Dimension | 36 * 27mm |
Encodeing format | PT2264 fixing code (same as PT2262 SC2262 ) ,Work with PT2272 decoder IC |
Transmitter distance | 100M (open area) |
Work mode
Wiring Diagram 2:
DC 1-48V OR AC 85-265V control circuit,Wiring diagram below(Note:If not DC 12V load, need another DC 12V power supply). "LOAD" may be LED lamp, fans, motors and other DC AC equipment
